GOE 647 AIRFOIL (goe647-il)

GOE 647 AIRFOIL - Gottingen 647 airfoil


Airfoil goe647-il
Details Dat file Parser
(goe647-il) GOE 647 AIRFOIL
Gottingen 647 airfoil
Max thickness 16.2% at 19.5% chord.
Max camber 5.3% at 39.4% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Lednicer format
GOE 647 AIRFOIL
       17.       17.

 0.0000000 0.0000000
 0.0111500 0.0314800
 0.0229800 0.0469900
 0.0470100 0.0695200
 0.0713000 0.0860700
 0.0957400 0.0991200
 0.1449400 0.1177300
 0.1945000 0.1278600
 0.2942800 0.1331500
 0.3944800 0.1284600
 0.4949800 0.1167800
 0.5957200 0.0996200
 0.6966100 0.0789500
 0.7976400 0.0548000
 0.8987700 0.0286500
 0.9493600 0.0148200
 1.0000000 0.0000000

 0.0000000 0.0000000
 0.0132100 -.0164300
 0.0259400 -.0218800
 0.0512000 -.0278000
 0.0763400 -.0312200
 0.1014300 -.0331400
 0.1515300 -.0354800
 0.2014800 -.0343400
 0.3012300 -.0285500
 0.4009100 -.0212600
 0.5006000 -.0139700
 0.6004000 -.0091800
 0.7002300 -.0053900
 0.8001300 -.0030900
 0.9000599 -.0013000
 0.9500500 -.0011500
 1.0000000 0.0000000
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

GOE 702 AIRFOILPreviewDetails
GOE 628 AIRFOILPreviewDetails
EPPLER 1210 AIRFOILPreviewDetails
GOE 645 AIRFOILPreviewDetails
GOE 626 AIRFOILPreviewDetails
St. CYR 234 (Bartel 17-IC)PreviewDetails
GOE 514 AIRFOILPreviewDetails
GOE 535 AIRFOILPreviewDetails
EPPLER 560 AIRFOILPreviewDetails
FX 73-CL1-152PreviewDetails

Polars for GOE 647 AIRFOIL (goe647-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   goe647-il50,000913.1 at α=1.25°Mach=0 Ncrit=9Xfoil predictionDetails
   goe647-il50,000528.3 at α=4.75°Mach=0 Ncrit=5Xfoil predictionDetails
   goe647-il100,000941.5 at α=4.25°Mach=0 Ncrit=9Xfoil predictionDetails
   goe647-il100,000544.5 at α=5.5°Mach=0 Ncrit=5Xfoil predictionDetails
   goe647-il200,000959 at α=5.25°Mach=0 Ncrit=9Xfoil predictionDetails
   goe647-il200,000558.5 at α=6°Mach=0 Ncrit=5Xfoil predictionDetails
   goe647-il500,000981.7 at α=5.25°Mach=0 Ncrit=9Xfoil predictionDetails
   goe647-il500,000581.3 at α=5.75°Mach=0 Ncrit=5Xfoil predictionDetails
   goe647-il1,000,0009105.8 at α=5.75°Mach=0 Ncrit=9Xfoil predictionDetails
   goe647-il1,000,0005104.3 at α=7°Mach=0 Ncrit=5Xfoil predictionDetails
