NACA 1412 (naca1412-il)

NACA 1412 - NACA 1412 airfoil


Airfoil naca1412-il
Details Dat file Parser
(naca1412-il) NACA 1412
NACA 1412 airfoil
Max thickness 12% at 29.9% chord.
Max camber 1% at 40% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Selig format
NACA 1412
1.00000     0.00126
0.95025     0.00966
0.90040     0.01753
0.80058     0.03178
0.70061     0.04413
0.60051     0.05453
0.50029     0.06267
0.40000     0.06803
0.29925     0.06940
0.24889     0.06799
0.19857     0.06486
0.14833     0.05951
0.09824     0.05118
0.07330     0.04537
0.04845     0.03786
0.02378     0.02733
0.01158     0.01954
0.00000     0.00000
0.01342     -0.01830
0.02622     -0.02491
0.05155     -0.03318
0.07670     -0.03857
0.10176     -0.04242
0.15167     -0.04733
0.20143     -0.04986
0.25111     -0.05081
0.30075     -0.05064
0.40000     -0.04803
0.49971     -0.04321
0.59949     -0.03675
0.69939     -0.02913
0.79942     -0.02066
0.89960     -0.01141
0.94975     -0.00646
1.00000     -0.00126
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

NPL 9627 AIRFOILPreviewDetails
S8052 (11.88%)PreviewDetails
S8055 (12%)PreviewDetails
NPL 9626 AIRFOILPreviewDetails
S4096 (designed for the E-flite UMXPreviewDetails
NACA 2412PreviewDetails
HAWKER TEMPEST 61% SEMISPAN AIRFOILPreviewDetails
S8038 (13%)PreviewDetails
HQ 1.0/12 AIRFOILPreviewDetails
RG 15A-1.8/11.0 AIRFOILPreviewDetails

Polars for NACA 1412 (naca1412-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   naca1412-il50,000929.6 at α=6.25°Mach=0 Ncrit=9Xfoil predictionDetails
   naca1412-il50,000531.2 at α=6°Mach=0 Ncrit=5Xfoil predictionDetails
   naca1412-il100,000944.1 at α=5.75°Mach=0 Ncrit=9Xfoil predictionDetails
   naca1412-il100,000543 at α=5.5°Mach=0 Ncrit=5Xfoil predictionDetails
   naca1412-il200,000957.6 at α=5.25°Mach=0 Ncrit=9Xfoil predictionDetails
   naca1412-il200,000553.3 at α=4.75°Mach=0 Ncrit=5Xfoil predictionDetails
   naca1412-il500,000973.5 at α=5°Mach=0 Ncrit=9Xfoil predictionDetails
   naca1412-il500,000566 at α=5.75°Mach=0 Ncrit=5Xfoil predictionDetails
   naca1412-il1,000,000983.8 at α=5°Mach=0 Ncrit=9Xfoil predictionDetails
   naca1412-il1,000,000578.6 at α=8.5°Mach=0 Ncrit=5Xfoil predictionDetails
