EPPLER 557 AIRFOIL (e557-il)

EPPLER 557 AIRFOIL - Eppler E557 general aviation airfoil


Airfoil e557-il
Details Dat file Parser
(e557-il) EPPLER 557 AIRFOIL
Eppler E557 general aviation airfoil
Max thickness 16% at 30.2% chord.
Max camber 3.7% at 60.8% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Lednicer format
EPPLER 557 AIRFOIL
       35.       37.

 0.0000100 0.0003800
 0.0001300 0.0020700
 0.0004500 0.0038500
 0.0015100 0.0072600
 0.0074800 0.0174300
 0.0178200 0.0283300
 0.0323800 0.0394500
 0.0510600 0.0504400
 0.0737300 0.0610100
 0.1002100 0.0709300
 0.1302800 0.0799800
 0.1636800 0.0879900
 0.2001100 0.0948000
 0.2392100 0.1002200
 0.2806900 0.1040700
 0.3243100 0.1062500
 0.3697500 0.1067900
 0.4166400 0.1057000
 0.4646000 0.1030600
 0.5132500 0.0989900
 0.5621100 0.0936400
 0.6107600 0.0871800
 0.6587300 0.0798400
 0.7054901 0.0718400
 0.7505500 0.0634300
 0.7933700 0.0548400
 0.8334100 0.0463100
 0.8701400 0.0380600
 0.9030400 0.0302600
 0.9316300 0.0230600
 0.9554700 0.0165700
 0.9741200 0.0107500
 0.9877200 0.0054200
 0.9966800 0.0014400
 1.0000000 0.0000000

 0.0000100 0.0003800
 0.0000300 -.0004200
 0.0001100 -.0011900
 0.0002700 -.0019200
 0.0005200 -.0026300
 0.0008700 -.0033400
 0.0012900 -.0040600
 0.0023300 -.0055300
 0.0036100 -.0070100
 0.0059600 -.0092600
 0.0163600 -.0162700
 0.0323600 -.0235500
 0.0531400 -.0304000
 0.0784600 -.0366900
 0.1079800 -.0423500
 0.1412500 -.0472900
 0.1777900 -.0513200
 0.2170900 -.0542200
 0.2586200 -.0556000
 0.3021600 -.0549100
 0.3478600 -.0518900
 0.3958100 -.0466100
 0.4461500 -.0394200
 0.4987200 -.0311100
 0.5529100 -.0224300
 0.6079700 -.0139500
 0.6630300 -.0061900
 0.7171700 0.0003900
 0.7693599 0.0054800
 0.8185700 0.0088600
 0.8637300 0.0104600
 0.9038301 0.0103900
 0.9379400 0.0088400
 0.9651200 0.0062100
 0.9846200 0.0032400
 0.9961900 0.0009000
 1.0000000 0.0000000
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

EPPLER 580 AIRFOILPreviewDetails
EPPLER 556 AIRFOILPreviewDetails
FX 83-W-160PreviewDetails
EPPLER 855 AIRFOILPreviewDetails
SM701PreviewDetails
NREL's S825 AirfoilPreviewDetails
EPPLER 558 AIRFOILPreviewDetails
EPPLER 559 AIRFOILPreviewDetails
EPPLER 555 AIRFOILPreviewDetails
SG6050PreviewDetails

Polars for EPPLER 557 AIRFOIL (e557-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   e557-il50,000925.4 at α=11°Mach=0 Ncrit=9Xfoil predictionDetails
   e557-il50,000532.3 at α=8.75°Mach=0 Ncrit=5Xfoil predictionDetails
   e557-il100,000953.7 at α=8.75°Mach=0 Ncrit=9Xfoil predictionDetails
   e557-il100,000554.9 at α=7.25°Mach=0 Ncrit=5Xfoil predictionDetails
   e557-il200,000975 at α=7.5°Mach=0 Ncrit=9Xfoil predictionDetails
   e557-il200,000573.1 at α=6.5°Mach=0 Ncrit=5Xfoil predictionDetails
   e557-il500,0009102.1 at α=6°Mach=0 Ncrit=9Xfoil predictionDetails
   e557-il500,000595.2 at α=5.5°Mach=0 Ncrit=5Xfoil predictionDetails
   e557-il1,000,0009122.1 at α=5.5°Mach=0 Ncrit=9Xfoil predictionDetails
   e557-il1,000,0005110.5 at α=5.25°Mach=0 Ncrit=5Xfoil predictionDetails
