E184 (8.33%) (e184-il)

E184 (8.33%) - Eppler E184 low Reynolds number airfoil


Airfoil e184-il
Details Dat file Parser
(e184-il) E184 (8.33%)
Eppler E184 low Reynolds number airfoil
Max thickness 8.3% at 33.3% chord.
Max camber 0.8% at 38.3% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Selig format
E184  (8.33%)
   1.00000  0.00000
   0.99676 -0.00015
   0.98705 -0.00052
   0.97084 -0.00086
   0.94823 -0.00075
   0.91969  0.00027
   0.88597  0.00242
   0.84781  0.00563
   0.80587  0.00981
   0.76081  0.01484
   0.71338  0.02055
   0.66428  0.02672
   0.61425  0.03306
   0.56400  0.03908
   0.51388  0.04433
   0.46424  0.04857
   0.41539  0.05158
   0.36763  0.05328
   0.32120  0.05362
   0.27634  0.05279
   0.23354  0.05101
   0.19328  0.04834
   0.15598  0.04490
   0.12204  0.04072
   0.09178  0.03591
   0.06552  0.03054
   0.04346  0.02472
   0.02580  0.01858
   0.01262  0.01229
   0.00397  0.00620
   0.00010  0.00091
   0.00189 -0.00382
   0.00938 -0.00854
   0.02188 -0.01302
   0.03935 -0.01707
   0.06166 -0.02058
   0.08869 -0.02350
   0.12020 -0.02584
   0.15590 -0.02760
   0.19544 -0.02882
   0.23841 -0.02952
   0.28437 -0.02976
   0.33280 -0.02958
   0.38317 -0.02902
   0.43492 -0.02814
   0.48747 -0.02698
   0.54020 -0.02557
   0.59253 -0.02396
   0.64387 -0.02217
   0.69362 -0.02025
   0.74122 -0.01823
   0.78612 -0.01613
   0.82782 -0.01400
   0.86584 -0.01185
   0.89973 -0.00972
   0.92911 -0.00763
   0.95362 -0.00555
   0.97313 -0.00343
   0.98765 -0.00154
   0.99683 -0.00036
   1.00000  0.00000
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

E182 (8.47%)PreviewDetails
BOEING-VERTOL VR-8 AIRFOIL WITH TABPreviewDetails
NACA 1408PreviewDetails
BOEING-VERTOL VR-8 AIRFOILPreviewDetails
EPPLER 874 HYDROFOIL AIRFOILPreviewDetails
NASA/LANGLEY RC-08(B)3 AIRFOILPreviewDetails
MH 23 8%PreviewDetails
S2055PreviewDetails
DU86-084/18 8.44%PreviewDetails
RG 14 AIRFOILPreviewDetails

Polars for E184 (8.33%) (e184-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   e184-il50,000930.9 at α=6°Mach=0 Ncrit=9Xfoil predictionDetails
   e184-il50,000531.7 at α=5.75°Mach=0 Ncrit=5Xfoil predictionDetails
   e184-il100,000944.4 at α=5.5°Mach=0 Ncrit=9Xfoil predictionDetails
   e184-il100,000543.2 at α=5.25°Mach=0 Ncrit=5Xfoil predictionDetails
   e184-il200,000958 at α=5°Mach=0 Ncrit=9Xfoil predictionDetails
   e184-il200,000553.5 at α=4.5°Mach=0 Ncrit=5Xfoil predictionDetails
   e184-il500,000973.9 at α=4.25°Mach=0 Ncrit=9Xfoil predictionDetails
   e184-il500,000563.9 at α=3.75°Mach=0 Ncrit=5Xfoil predictionDetails
   e184-il1,000,000982.4 at α=3.75°Mach=0 Ncrit=9Xfoil predictionDetails
   e184-il1,000,000567 at α=3.25°Mach=0 Ncrit=5Xfoil predictionDetails
