RG-15 8.9% (rg15-il)

RG-15 8.9% - Rolf Girsberger RG 15 low Reynolds number airfoil


Airfoil rg15-il
Details Dat file Parser
(rg15-il) RG-15 8.9%
Rolf Girsberger RG 15 low Reynolds number airfoil
Max thickness 8.9% at 30.2% chord.
Max camber 1.8% at 39.7% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Selig format
  RG-15 8.9%
  1.00000  0.0
  0.99671  0.00054
  0.98726  0.00229
  0.97237  0.00514
  0.95248  0.00865
  0.92764  0.01254
  0.89810  0.01685
  0.86427  0.02152
  0.82660  0.02644
  0.78557  0.03149
  0.74165  0.03654
  0.69537  0.04146
  0.64723  0.04612
  0.59778  0.05039
  0.54753  0.05414
  0.49702  0.05727
  0.44676  0.05966
  0.39727  0.06123
  0.34902  0.06190
  0.30248  0.06162
  0.25809  0.06036
  0.21624  0.05810
  0.17730  0.05486
  0.14161  0.05068
  0.10945  0.04564
  0.08108  0.03985
  0.05673  0.03343
  0.03658  0.02654
  0.02076  0.01935
  0.00932  0.01214
  0.00235  0.00526
  0.0      0.0
  0.00002 -0.00048
  0.00336 -0.00534
  0.01247 -0.01006
  0.02670 -0.01436
  0.04596 -0.01811
  0.07010 -0.02123
  0.09896 -0.02372
  0.13224 -0.02559
  0.16963 -0.02688
  0.21073 -0.02762
  0.25509 -0.02785
  0.30221 -0.02762
  0.35156 -0.02696
  0.40257 -0.02590
  0.45463 -0.02446
  0.50713 -0.02262
  0.55944 -0.02025
  0.61128 -0.01717
  0.66244 -0.01366
  0.71237 -0.01015
  0.76037 -0.00691
  0.80575 -0.00413
  0.84779 -0.00192
  0.88583 -0.00034
  0.91925  0.00062
  0.94748  0.00101
  0.97003  0.00097
  0.98652  0.00064
  0.99660  0.00021
  1.00000  0.0
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

MH 42 8.94%PreviewDetails
MH 20 9.01%PreviewDetails
RG 14 9% AIRFOILPreviewDetails
S7012 8.75%PreviewDetails
RG 14 AIRFOILPreviewDetails
MH 43 8.5%PreviewDetails
E180 (8.59%)PreviewDetails
SD7080 (9.2%)PreviewDetails
S9000 (9%)PreviewDetails
AG35PreviewDetails

Polars for RG-15 8.9% (rg15-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   rg15-il50,000934.8 at α=6°Mach=0 Ncrit=9Xfoil predictionDetails
   rg15-il50,000536.6 at α=5.75°Mach=0 Ncrit=5Xfoil predictionDetails
   rg15-il100,000952.1 at α=5.25°Mach=0 Ncrit=9Xfoil predictionDetails
   rg15-il100,000550.5 at α=5°Mach=0 Ncrit=5Xfoil predictionDetails
   rg15-il200,000968.8 at α=4.5°Mach=0 Ncrit=9Xfoil predictionDetails
   rg15-il200,000563.2 at α=4.5°Mach=0 Ncrit=5Xfoil predictionDetails
   rg15-il500,000989 at α=3.75°Mach=0 Ncrit=9Xfoil predictionDetails
   rg15-il500,000579 at α=4.25°Mach=0 Ncrit=5Xfoil predictionDetails
   rg15-il1,000,0009102.5 at α=3.75°Mach=0 Ncrit=9Xfoil predictionDetails
   rg15-il1,000,000588.7 at α=4.75°Mach=0 Ncrit=5Xfoil predictionDetails
