NACA 4421 (naca4421-il)

NACA 4421 - NACA 4421 airfoil


Airfoil naca4421-il
Details Dat file Parser
(naca4421-il) NACA 4421
NACA 4421 airfoil
Max thickness 21% at 30% chord.
Max camber 4% at 40% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Selig format
NACA 4421
1.0000     0.0022
0.9500     0.0211
0.9000     0.0385
0.8000     0.0691
0.7000     0.0950
0.6000     0.1160
0.5000     0.1318
0.4000     0.1416
0.3000     0.1427
0.2500     0.1388
0.2000     0.1317
0.1500     0.1204
0.1000     0.1035
0.0750     0.0924
0.0500     0.0782
0.0250     0.0584
0.0125     0.0445
0.0000     0.0000
0.0125     -0.0242
0.0250     -0.0348
0.0500     -0.0478
0.0750     -0.0562
0.1000     -0.0615
0.1500     -0.0675
0.2000     -0.0698
0.2500     -0.0692
0.3000     -0.0676
0.4000     -0.0616
0.5000     -0.0534
0.6000     -0.0440
0.7000     -0.0335
0.8000     -0.0231
0.9000     -0.0127
0.9500     -0.0074
1.0000     -0.0022
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

DEFIANT CANARD BL20 AIRFOILPreviewDetails
GOE 770 AIRFOILPreviewDetails
AH 93-W-215PreviewDetails
HAM-STD HS1-620 AIRFOILPreviewDetails
EPPLER 857 AIRFOILPreviewDetails
GOE 383 AIRFOILPreviewDetails
GOE 735 AIRFOILPreviewDetails
FX 84-W-218PreviewDetails
GOE 386 AIRFOILPreviewDetails
ONERA HOR20 AIRFOILPreviewDetails

Polars for NACA 4421 (naca4421-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   naca4421-il50,00093.6 at α=10.75°Mach=0 Ncrit=9Xfoil predictionDetails
   naca4421-il50,000515.3 at α=2.25°Mach=0 Ncrit=5Xfoil predictionDetails
   naca4421-il100,000936.1 at α=9.75°Mach=0 Ncrit=9Xfoil predictionDetails
   naca4421-il100,000541.9 at α=5.5°Mach=0 Ncrit=5Xfoil predictionDetails
   naca4421-il200,000961.2 at α=7.5°Mach=0 Ncrit=9Xfoil predictionDetails
   naca4421-il200,000558.4 at α=6.5°Mach=0 Ncrit=5Xfoil predictionDetails
   naca4421-il500,000983.3 at α=5.75°Mach=0 Ncrit=9Xfoil predictionDetails
   naca4421-il500,000578.1 at α=6°Mach=0 Ncrit=5Xfoil predictionDetails
   naca4421-il1,000,0009103.1 at α=5.75°Mach=0 Ncrit=9Xfoil predictionDetails
   naca4421-il1,000,000593.2 at α=5.75°Mach=0 Ncrit=5Xfoil predictionDetails
