EPPLER E837 HYDROFOIL AIRFOIL (e837-il)

EPPLER E837 HYDROFOIL AIRFOIL - Eppler E837 hydrofoil


Airfoil e837-il
Details Dat file Parser
(e837-il) EPPLER E837 HYDROFOIL AIRFOIL
Eppler E837 hydrofoil
Max thickness 16.1% at 36.9% chord.
Max camber 0% at 0% chord
Source UIUC Airfoil Coordinates Database
Source dat file
The dat file is in Lednicer format
EPPLER E837 HYDROFOIL AIRFOIL
      31.0      31.0

 0.0000000 0.0000000
 0.0031600 0.0072000
 0.0119800 0.0155600
 0.0256400 0.0243100
 0.0438800 0.0330700
 0.0664900 0.0415900
 0.0932500 0.0496400
 0.1238900 0.0570500
 0.1581000 0.0636700
 0.1955400 0.0693500
 0.2358200 0.0740000
 0.2785400 0.0774900
 0.3232300 0.0797100
 0.3694300 0.0805300
 0.4167400 0.0797500
 0.4649100 0.0772600
 0.5136500 0.0731000
 0.5627100 0.0673700
 0.6118300 0.0602800
 0.6607800 0.0522200
 0.7091200 0.0437800
 0.7561500 0.0354800
 0.8010900 0.0276900
 0.8431900 0.0207100
 0.8816400 0.0147400
 0.9156900 0.0098700
 0.9446200 0.0060700
 0.9679500 0.0031600
 0.9853399 0.0011800
 0.9962500 0.0002200
 1.0000000 0.0000000

 0.0000000 0.0000000
 0.0031600 -.0072000
 0.0119800 -.0155600
 0.0256400 -.0243100
 0.0438800 -.0330700
 0.0664900 -.0415900
 0.0932500 -.0496400
 0.1238900 -.0570500
 0.1581000 -.0636700
 0.1955400 -.0693500
 0.2358200 -.0740000
 0.2785400 -.0774900
 0.3232300 -.0797100
 0.3694300 -.0805300
 0.4167400 -.0797500
 0.4649100 -.0772600
 0.5136500 -.0731000
 0.5627100 -.0673700
 0.6118300 -.0602800
 0.6607800 -.0522200
 0.7091200 -.0437800
 0.7561500 -.0354800
 0.8010900 -.0276900
 0.8431900 -.0207100
 0.8816400 -.0147400
 0.9156900 -.0098700
 0.9446200 -.0060700
 0.9679500 -.0031600
 0.9853399 -.0011800
 0.9962500 -.0002200
 1.0000000 0.0000000
No parser warnings Send to airfoil plotter
Add to comparison
Lednicer format dat file
Selig format dat file

Similar airfoils

S1014PreviewDetails
WORTMANN FX L V-152 AIRFOILPreviewDetails
GOE 410 AIRFOILPreviewDetails
EPPLER 520 AIRFOILPreviewDetails
NACA 63-015A AIRFOILPreviewDetails
NACA 642-015 AIRFOILPreviewDetails
FX 71-L-150/20 AIRFOILPreviewDetails
FX 71-L-150/25 AIRFOILPreviewDetails
FX 71-L-150/30 AIRFOILPreviewDetails
FX 71-L-150/30 AIRFOILPreviewDetails

Polars for EPPLER E837 HYDROFOIL AIRFOIL (e837-il)

PlotAirfoilReynolds #NcritMax Cl/CdDescriptionSource
   e837-il50,000926.6 at α=8.25°Mach=0 Ncrit=9Xfoil predictionDetails
   e837-il50,000525.5 at α=7.25°Mach=0 Ncrit=5Xfoil predictionDetails
   e837-il100,000943.2 at α=7.25°Mach=0 Ncrit=9Xfoil predictionDetails
   e837-il100,000537.7 at α=7.25°Mach=0 Ncrit=5Xfoil predictionDetails
   e837-il200,000953 at α=7.25°Mach=0 Ncrit=9Xfoil predictionDetails
   e837-il200,000550.3 at α=6.25°Mach=0 Ncrit=5Xfoil predictionDetails
   e837-il500,000970.6 at α=6°Mach=0 Ncrit=9Xfoil predictionDetails
   e837-il500,000561.2 at α=5.25°Mach=0 Ncrit=5Xfoil predictionDetails
   e837-il1,000,000980.1 at α=5.25°Mach=0 Ncrit=9Xfoil predictionDetails
   e837-il1,000,000565.7 at α=4.25°Mach=0 Ncrit=5Xfoil predictionDetails
